关于 python：如何在带有 Coral 的 Raspberry Pi 上使用带有 2 个类的自定义 TFlite 模型？

How to use a custom TF.lite model with 2 classes on a Rasperry Pi with a Coral?

两天前，我在 Tflite 中根据图像数据集创建了一个自定义模型。准确率为 97.4 %，它只有 2 个类(人、花)

我将模型转换为在我的 Rasberry Pi 中使用 TPU Google Coral。

目前，我遇到了一些问题。 Google Coral 的文档并不适合我。

语言：Python3

图书馆

喀拉斯
张量流
枕头
皮卡梅拉
麻木的
EdgeTPU-引擎

项目树：

——–>模型(子文件夹)

———–>model.tflite

———–>labels.txt

——–>video_detection.py

这是 Python 代码：(实际上代码来自文档)

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42

import argparse
import io
import time
import numpy as np
import picamera
import edgetpu.classification.engine
def main():
parser = argparse.ArgumentParser()
parser.add_argument(
‘–model’, help=‘File path of Tflite model.’, required=True)
parser.add_argument(
‘–label’, help=‘File path of label file.’, required=True)
args = parser.parse_args()
with open(args.label, ‘r’, encoding=“utf-8”) as f:
pairs = (l.strip().split(maxsplit=2) for l in f.readlines())
labels = dict((int(k), v) for k, v in pairs)
engine = edgetpu.classification.engine.ClassificationEngine(args.model)
with picamera.PiCamera() as camera:
camera.resolution = (640, 480)
camera.framerate = 30
_, width, height, channels = engine.get_input_tensor_shape()
camera.start_preview()
try:
stream = io.BytesIO()
for foo in camera.capture_continuous(stream,
format=‘rgb’,
use_video_port=True,
resize=(width, height)):
stream.truncate()
stream.seek(0)
input = np.frombuffer(stream.getvalue(), dtype=np.uint8)
start_ms = time.time()
results = engine.ClassifyWithInputTensor(input, top_k=1)
elapsed_ms = time.time() – start_ms
if results:
camera.annotate_text =“%s %.2f\
%.2fms” % (
labels[results[0][0]], results[0][1], elapsed_ms*1000.0)
finally:
camera.stop_preview()
if __name__ == ‘__main__’:
main()

如何运行脚本

python3 video_detection.py –model model/model.tflite –label model/labels.txt

错误

1
2
3
4
5
6
7
8

`Traceback (most recent call last):
File“video_detection.py”, line 41, in <module>
main()
File“video_detection.py”, line 16, in main
labels = dict((int(k), v) for k, v in pairs)
File“video_detection.py”, line 16, in <genexpr>
labels = dict((int(k), v) for k, v in pairs)
ValueError: not enough values to unpack (expected 2, got 1)`

对我来说，现在很难集成自定义模型并将其与珊瑚一起使用。

文档：

https://coral.withgoogle.com/docs/edgetpu/models-intro/
https://coral.withgoogle.com/docs/edgetpu/api-intro/
https://coral.withgoogle.com/docs/edgetpu/tflite-python/
https://coral.googlesource.com/edgetpu/ /refs/heads/release-chef/edgetpu/

感谢阅读，问候

错误在labels.txt文件中：

1 2	labels = dict((int(k), v) for k, v in pairs) ValueError: not enough values to unpack (expected 2, got 1)`

看起来你有一些行只有一个值而不是两个
