android自定义listview

本文概述

• 自定义我们的ListView

创建简单的ListView之后，android还提供了自定义ListView的功能。

作为简单的ListView，自定义ListView还使用Adapter类，该类添加了数据源中的内容（例如字符串数组，数组，数据库等）。适配器在AdapterView和其他视图之间桥接数据

自定义ListView的示例

在此自定义listview示例中，我们将添加图像，带有标题的文本及其副标题。

自定义listview项目的结构

activity_main.xml

在布局文件夹中创建一个activity_main.xml文件。

文件：activity_main.xml

<?xml version="1.0" encoding="utf-8"?>
<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:paddingBottom="@dimen/activity_vertical_margin"
    android:paddingLeft="@dimen/activity_horizontal_margin"
    android:paddingRight="@dimen/activity_horizontal_margin"
    android:paddingTop="@dimen/activity_vertical_margin"
    tools:context="com.example.test.listviewwithimage.MainActivity">

    <ListView
        android:id="@+id/list"
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:layout_marginBottom="50dp">
    </ListView>
</RelativeLayout>

在布局文件夹中创建一个额外的mylist.xml文件，其中包含在listview中显示的视图组件。

mylist.xml

档案：mylist.xml

<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:orientation="horizontal" >

    <ImageView
        android:id="@+id/icon"
        android:layout_width="60dp"
        android:layout_height="60dp"
		android:padding="5dp" />

    <LinearLayout android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:orientation="vertical">

    <TextView
        android:id="@+id/title"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:text="Medium Text"
        android:textStyle="bold"
        android:textAppearance="?android:attr/textAppearanceMedium"
        android:layout_marginLeft="10dp"
        android:layout_marginTop="5dp"
        android:padding="2dp"
        android:textColor="#4d4d4d" />
    <TextView
        android:id="@+id/subtitle"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:text="TextView"
        android:layout_marginLeft="10dp"/>
	</LinearLayout>
</LinearLayout>

将所有必需的图像放置在可绘制文件夹中。

活动类

文件：MainActivity.java

package com.example.test.listviewwithimage;

import android.support.v7.app.AppCompatActivity;
import android.os.Bundle;
import android.view.View;
import android.widget.AdapterView;
import android.widget.ListView;
import android.widget.Toast;

public class MainActivity extends AppCompatActivity {
    ListView list;

    String[] maintitle ={
            "Title 1", "Title 2", "Title 3", "Title 4", "Title 5", };

    String[] subtitle ={
            "Sub Title 1", "Sub Title 2", "Sub Title 3", "Sub Title 4", "Sub Title 5", };

    Integer[] imgid={
            R.drawable.download_1, R.drawable.download_2, R.drawable.download_3, R.drawable.download_4, R.drawable.download_5, };
    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);

        MyListAdapter adapter=new MyListAdapter(this, maintitle, subtitle, imgid);
        list=(ListView)findViewById(R.id.list);
        list.setAdapter(adapter);


        list.setOnItemClickListener(new AdapterView.OnItemClickListener() {

            @Override
            public void onItemClick(AdapterView<?> parent, View view, int position, long id) {
                // TODO Auto-generated method stub
                if(position == 0) {
                    //code specific to first list item
                    Toast.makeText(getApplicationContext(), "Place Your First Option Code", Toast.LENGTH_SHORT).show();
                }

                else if(position == 1) {
                    //code specific to 2nd list item
                    Toast.makeText(getApplicationContext(), "Place Your Second Option Code", Toast.LENGTH_SHORT).show();
                }

                else if(position == 2) {

                    Toast.makeText(getApplicationContext(), "Place Your Third Option Code", Toast.LENGTH_SHORT).show();
                }
                else if(position == 3) {

                    Toast.makeText(getApplicationContext(), "Place Your Forth Option Code", Toast.LENGTH_SHORT).show();
                }
                else if(position == 4) {

                    Toast.makeText(getApplicationContext(), "Place Your Fifth Option Code", Toast.LENGTH_SHORT).show();
                }

            }
        });
    }
}

---

自定义我们的ListView

创建另一个扩展ArrayAdapter类的Java类MyListView.java。此类自定义我们的列表视图。

MyListView.java

package com.example.test.listviewwithimage;

import android.app.Activity;

import android.view.LayoutInflater;
import android.view.View;
import android.view.ViewGroup;
import android.widget.ArrayAdapter;
import android.widget.ImageView;
import android.widget.TextView;

public class MyListAdapter extends ArrayAdapter<String> {

    private final Activity context;
    private final String[] maintitle;
    private final String[] subtitle;
    private final Integer[] imgid;

    public MyListAdapter(Activity context, String[] maintitle, String[] subtitle, Integer[] imgid) {
        super(context, R.layout.mylist, maintitle);
        // TODO Auto-generated constructor stub

        this.context=context;
        this.maintitle=maintitle;
        this.subtitle=subtitle;
        this.imgid=imgid;

    }

    public View getView(int position, View view, ViewGroup parent) {
        LayoutInflater inflater=context.getLayoutInflater();
        View rowView=inflater.inflate(R.layout.mylist, null, true);

        TextView titleText = (TextView) rowView.findViewById(R.id.title);
        ImageView imageView = (ImageView) rowView.findViewById(R.id.icon);
        TextView subtitleText = (TextView) rowView.findViewById(R.id.subtitle);

        titleText.setText(maintitle[position]);
        imageView.setImageResource(imgid[position]);
        subtitleText.setText(subtitle[position]);

        return rowView;

    };
}

输出量
